Product Details:
|
| Advantage 1: | Energy Saving | Advantage 2: | High Efficiency |
|---|---|---|---|
| Advantage 3: | Reliable | Safety 1: | Hydraulic Lock For Furnace |
| Safety 2: | Detecting System For Molten Iron Leakage Out Of Furnace | Safety 3: | Interlock Of Power Supply Cabinet Door |
| Safety 4: | Protection Against Accident Due To High Temperature Of Water And Water Leakage | Safety 5: | Grounding Protection |
| Safety 6: | Drop-roof Hood Of Furnace | Safety 7: | Emergency Power Supply |
| Safety 8: | Resin-poured Impedance With Empty Core | ||
| Highlight: | Medium Frequency Steel Melting Furnace,China Steel Melting Furnace,Energy Saving Steel Melting Furnace |
||
China transistor medium frequency
steel melting furnace with energy saving advantage
Features:
1. Serial connection type medium frequency smelting system with one power cabinet and two furnaces is composed of a set of serial-connection resonant dual output power cabinet and two smelting furnaces. Output power can randomly be distributed in stepless form between the two furnace bodies, and the two furnace can be powered simultaneously, one is for insulation and the other is for smelting, other additional switching device is not needed any more for switching the two furnace.
2.Our serially-connected resonance design guarantees continuous and stable operation of the equipment and it has a wide load matching range. Rectifier part of power cabinet adopts fully open design, so power factor is high and high harmonics is low.
3. Higher utilization rate of transformer can help you save 15% of transformer capacity landline fee
Advantages:
1. Power from one set of power cabinet can be synchronously distributed to two smelting furnaces at your any random requirements, one furnace is for smelting, the other one is for insulation synchronously, achieving continuous supply of molten iron in pouring line
2. Smelting system with one power cabinet and two furnaces can make two furnaces melt raw material simultaneously, this can achieve large part casting process and it can also be applied in casting process with any small tonnage or large tonnage
Main technical data of one power supply for both two furances
| Type |
Input power V |
Input current A | Direct current voltage V | Input current A |
Medium frequency voltage (±10％)V |
Medium frequency Hz | Power of medium frequency Kw |
| DX-250Kw | 380V/ three phase | 406A | 500V | 500A | 1200V | 100-500Hz | 250Kw |
| DX-500Kw | 816A | 1000A | 500Kw | ||||
| DX-800Kw | 1305A | 1600A | 800Kw | ||||
| DX-1000Kw | 380V/six phase | 816A | 1000V | 1000A | 2400V | 100-400Hz | 1000Kw |
| DX-1500Kw | 1220A | 1500A | 1500Kw | ||||
| DX-2000Kw | 1630A | 2000A | 2000Kw | ||||
| DX-2500Kw | 2040A | 2500A | 2500Kw | ||||
| DX-3000Kw | 660V/six phase | 1312A | 1800V | 1600A | 2900V | 100-300Hz | 3000Kw |
| DX-3500Kw | 1530A | 1900A | 3500Kw | ||||
| DX-4000Kw | 1749A | 2100A | 4000Kw | ||||
| DX-4500Kw | 1968A | 2400A | 4500Kw | ||||
| DX-5000Kw | 750V/six phase | 1924A | 2000V | 2400A | 3400V | 100-250Hz | 5000Kw |
| DX-6000Kw | 2309A | 2800A | 6000Kw | ||||
| DX-8000Kw | 3079A | 3800A | 8000Kw | ||||
| DX-10000Kw | 1000V/twelve phase | 1443A | 1600V | 1800A | 3600V | 100-200Hz | 10000Kw |
| DX-15000Kw | 2165A | 2700A | 15000Kw |
